Description for evaporator coil
We can supply many kinds of Walk-In Evaporators:
- Roof Mounted
- Blast Design Type(Vertical Type)
- Double Side Blowing
- Floor Standing Type
Many types of evaporator coils with different fans
Coil with 2 fans
Coil with 3 fans
Coil with 4 fans
Coil with 6 fans
Choosing the Right Evaporator for Your Needs
Assessing Size and Capacity
Let us help you find the perfect fit. Consider the size of your space and the volume of products to ensure you select a cooler with the right capacity.
Tailored for Various Applications
Whether it’s food processing, pharmaceuticals, or any other industry requiring precise temperature control, our coolers are up to the task.
Customization Options
We understand that one size doesn’t fit all. Explore our customization options to find the perfect configuration for your unique needs.
Product Features
1.Evaporator Details:
- Dimension(L*W*H): Customized
- Fin material: Copper, Aluminum, SUS304, Hydrophilic aluminum foil, and Epoxy Coating
- Fin space: 4 – 10 mm
- Tube material: Copper, Aluminum, SUS304, etc.
Epoxy fins Hydrophilic aluminum foil
Evaporator air cooler with Epoxy fins
2. Features of Roof-Mount Fan Coil Unit
CRYO has DL, DD, DJ series of walk-in evaporators for different range temperatures needed.
DL air cooler for -5~+5 degree C, mainly used for chiller room.
DD for -15~-25 degree C, mainly use for freezer room.
DJ for -25~-40 degress C, mainly use for blast freezer room
- Cabinet of magnalium steel, corrosion-proof
- Fin space: 4.5mm, 6.0mm and 9.0mm
- Refrigerant: R22, R404A, R507A, etc
- Stainless steel heater, defrosting evenly
- Double water receivers, more stable
- Mechanically expanded pipes with Aluminium fins
- Long-distance air throw is optional
3. Features of Double-side Blow Evaporator
DHF Series Double Side Blowing unit cooler is always used in the processing plant workshop, which is soft air blowing and suitable for working inside.
By the suited temperature, it is divided into 2 series: L, D. suited for the room requiring 0℃, -18℃.
- The shell is of aluminum and magnesium alloy plate, corrosion resistant, and beautiful outlook.
- The coil is of a crossed-arranged inner screw copper tube, with high heat exchange efficiency.
- Assembled with an axial fan, with double-side air-blowing, soft and low noise.
- The electric heating tube of stainless steel is deployed inside the coil, having a good defrosting effect.
4. Features of Vertical Type Evaporator
Vertical Blast Freezing Air Cooler：
- Models available with 2, 4, 6 & 8 Fans
- Temp Ranging from -5 °C (Blast chiller) to -45 °C (Blast Freezer)
- Fin spacing available from 4 mm to 10 mm
- Cooling capacity ranging from 5 kW to 130 kW
- Huge heat-transfer surface
Successful Case
Large Cold Room With Evaporator Coil with 4 Fans
Processing room with soft double blow evaporator
For more: you could get in touch with us and leave your message to get the latest price and ask questions, and we will reply as soon as possible.
We provide the one-stop solution cold room with high-quality refrigeration systems(also with the refrigeration accessories)
Any need please contact us!
